Enclosure Drill Jigs

Product Overview

Simplify your custom enclosure making!

These drill jigs from Keech Design slide neatly over your enclosure and allow you to center-punch and drill component holes in any number of locations based on your custom layout!

More information is here: https://www.keechdesign.com/

Product Videos

Videos Hide Videos Show Videos

Drilling Fixture for 1590B style enclosures: How To Use

Visit https://keech-design-consulting.square.site/ to pre-orde...

Reviews

(3 reviews) Write a Review

3 Reviews Hide Reviews Show Reviews

5
Enclosure Drill jig

Posted by Andrew on 06/7/23

Saves time and results are always bang on, scored & drill 3 enclosures in the same time it would take to do one, very happy with purchase!
5
Best you can get!

Posted by MG on 05/28/23

Used this recently on a pedalpcb build and it made drilling the holes in the enclosure super easy after using the jig and a spring loaded center punch. This is a great improvement over the other template I was using since it covers 4 sides of the enclosure, ensuring the holes stay square. Highly recommended!
5
One of my favorite tools

Posted by D.A. on 04/9/23

These are such a huge help to making one of the more tedious parts of the building process a breeze. Glad that they are being carried here! One of my fav tools to use.
